# Spring3 Hornetq 獨立集成示例 > 原文： [https://howtodoinjava.com/hornetq/spring-3-hornetq-standalone-integration-example/](https://howtodoinjava.com/hornetq/spring-3-hornetq-standalone-integration-example/) [**HornetQ**](http://hornetq.jboss.org "hornetq") 是一個開放源代碼項目，旨在構建多協議，可嵌入，非常高性能的集群異步消息傳遞系統。 到目前為止，我們已經了解了[**配置 hornetq 獨立服務器**](//howtodoinjava.com/hornetq/hornetq-stand-alone-server-example-using-maven/ "Hornetq stand alone server example using maven")和[**設置基本消息傳遞功能**](//howtodoinjava.com/hornetq/basic-jms-messaging-example-using-hornetq-stand-alone-server/ "Basic jms messaging example using hornetq stand alone server")的示例。 HornetQ 具有很大的靈活性，可以通過一些現有的應用框架進行配置。 在此序列中，我將展示 HornetQ 在 [**Spring3**](//howtodoinjava.com "Spring3 tutorials") 中的用法。 讓我們逐步進行所有設置。 步驟 1）[創建一個 Maven 項目](//howtodoinjava.com/maven/create-a-simple-java-project-using-maven/ "Create a simple java project using maven")并將其轉換為 Eclipse Java 項目。 步驟 2）使用 Spring3 和 hornetq 依賴項更新 maven 倉庫。 ```java <project xmlns="http://maven.apache.org/POM/4.0.0" xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance" xsi:schemaLocation="http://maven.apache.org/POM/4.0.0 http://maven.apache.org/maven-v4_0_0.xsd"> <modelVersion>4.0.0</modelVersion> <groupId>com.howtodoinjava.app</groupId> <artifactId>Spring3HornetQStandaloneIntegration</artifactId> <packaging>jar</packaging> <version>1.0-SNAPSHOT</version> <name>Spring3HornetQStandaloneIntegration</name> <url>http://maven.apache.org</url> <properties> <org.springframework.version>3.0.5.RELEASE</org.springframework.version> </properties> <dependencies> <!-- User Application Lib --> <dependency> <groupId>commons-logging</groupId> <artifactId>commons-logging</artifactId> <version>1.1.1</version> </dependency> <dependency> <groupId>log4j</groupId> <artifactId>log4j</artifactId> <version>1.2.14</version> </dependency> <dependency> <groupId>junit</groupId> <artifactId>junit</artifactId> <version>4.7</version> <scope>test</scope> </dependency> <!-- HornetQ Embedded Server --> <dependency> <groupId>org.hornetq</groupId> <artifactId>hornetq-core</artifactId> <version>2.0.0.GA</version> <scope>compile</scope> </dependency> <dependency> <groupId>org.hornetq</groupId> <artifactId>hornetq-jms</artifactId> <version>2.0.0.GA</version> <scope>compile</scope> </dependency> <dependency> <groupId>org.hornetq</groupId> <artifactId>hornetq-logging</artifactId> <version>2.0.0.GA</version> <scope>compile</scope> </dependency> <dependency> <groupId>org.hornetq</groupId> <artifactId>hornetq-transports</artifactId> <version>2.0.0.GA</version> <scope>compile</scope> </dependency> <dependency> <groupId>org.jboss.netty</groupId> <artifactId>netty</artifactId> <version>3.1.0.GA</version> </dependency> <dependency> <groupId>org.jboss.javaee</groupId> <artifactId>jboss-jms-api</artifactId> <version>1.1.0.GA</version> <scope>compile</scope> </dependency> <dependency> <groupId>org.jboss</groupId> <artifactId>jboss-common-core</artifactId> <version>2.2.10.GA</version> </dependency> <dependency> <groupId>org.jboss.logging</groupId> <artifactId>jboss-logging-spi</artifactId> <version>2.0.5.GA</version> </dependency> <!-- Core utilities used by other modules. Define this if you use Spring Utility APIs (org.springframework.core.*/org.springframework.util.*) --> <dependency> <groupId>org.springframework</groupId> <artifactId>spring-core</artifactId> <version>${org.springframework.version}</version> </dependency> <!-- Expression Language (depends on spring-core) Define this if you use Spring Expression APIs (org.springframework.expression.*) --> <dependency> <groupId>org.springframework</groupId> <artifactId>spring-expression</artifactId> <version>${org.springframework.version}</version> </dependency> <!-- Bean Factory and JavaBeans utilities (depends on spring-core) Define this if you use Spring Bean APIs (org.springframework.beans.*) --> <dependency> <groupId>org.springframework</groupId> <artifactId>spring-beans</artifactId> <version>${org.springframework.version}</version> </dependency> <!-- Aspect Oriented Programming (AOP) Framework (depends on spring-core, spring-beans) Define this if you use Spring AOP APIs (org.springframework.aop.*) --> <dependency> <groupId>org.springframework</groupId> <artifactId>spring-aop</artifactId> <version>${org.springframework.version}</version> </dependency> <!-- Application Context (depends on spring-core, spring-expression, spring-aop, spring-beans) This is the central artifact for Spring's Dependency Injection Container and is generally always defined --> <dependency> <groupId>org.springframework</groupId> <artifactId>spring-context</artifactId> <version>${org.springframework.version}</version> </dependency> <!-- Various Application Context utilities, including EhCache, JavaMail, Quartz, and Freemarker integration Define this if you need any of these integrations --> <dependency> <groupId>org.springframework</groupId> <artifactId>spring-context-support</artifactId> <version>${org.springframework.version}</version> </dependency> <!-- Transaction Management Abstraction (depends on spring-core, spring-beans, spring-aop, spring-context) Define this if you use Spring Transactions or DAO Exception Hierarchy (org.springframework.transaction.*/org.springframework.dao.*) --> <dependency> <groupId>org.springframework</groupId> <artifactId>spring-tx</artifactId> <version>${org.springframework.version}</version> </dependency> <!-- JDBC Data Access Library (depends on spring-core, spring-beans, spring-context, spring-tx) Define this if you use Spring's JdbcTemplate API (org.springframework.jdbc.*) --> <dependency> <groupId>org.springframework</groupId> <artifactId>spring-jdbc</artifactId> <version>${org.springframework.version}</version> </dependency> <!-- Object-to-Relation-Mapping (ORM) integration with Hibernate, JPA, and iBatis. (depends on spring-core, spring-beans, spring-context, spring-tx) Define this if you need ORM (org.springframework.orm.*) --> <dependency> <groupId>org.springframework</groupId> <artifactId>spring-orm</artifactId> <version>${org.springframework.version}</version> </dependency> <!-- Object-to-XML Mapping (OXM) abstraction and integration with JAXB, JiBX, Castor, XStream, and XML Beans. (depends on spring-core, spring-beans, spring-context) Define this if you need OXM (org.springframework.oxm.*) --> <dependency> <groupId>org.springframework</groupId> <artifactId>spring-oxm</artifactId> <version>${org.springframework.version}</version> </dependency> <!-- Web application development utilities applicable to both Servlet and Portlet Environments (depends on spring-core, spring-beans, spring-context) Define this if you use Spring MVC, or wish to use Struts, JSF, or another web framework with Spring (org.springframework.web.*) --> <dependency> <groupId>org.springframework</groupId> <artifactId>spring-web</artifactId> <version>${org.springframework.version}</version> </dependency> <!-- Spring MVC for Servlet Environments (depends on spring-core, spring-beans, spring-context, spring-web) Define this if you use Spring MVC with a Servlet Container such as Apache Tomcat (org.springframework.web.servlet.*) --> <dependency> <groupId>org.springframework</groupId> <artifactId>spring-webmvc</artifactId> <version>${org.springframework.version}</version> </dependency> <!-- Spring MVC for Portlet Environments (depends on spring-core, spring-beans, spring-context, spring-web) Define this if you use Spring MVC with a Portlet Container (org.springframework.web.portlet.*) --> <dependency> <groupId>org.springframework</groupId> <artifactId>spring-webmvc-portlet</artifactId> <version>${org.springframework.version}</version> </dependency> <!-- Support for testing Spring applications with tools such as JUnit and TestNG This artifact is generally always defined with a 'test' scope for the integration testing framework and unit testing stubs --> <dependency> <groupId>org.springframework</groupId> <artifactId>spring-test</artifactId> <version>${org.springframework.version}</version> <scope>test</scope> </dependency> </dependencies> </project> ``` 步驟 3）在`lib`文件夾中添加兩個其他 jar。 如果時間允許，請找到它們的 Maven 依賴項并添加`pom.xml`。 * `jnpserver-5.0.3.GA.jar` * `org.springframework.jms-3.0.5.RELEASE.jar` 步驟 4）從 jboss 發行版復制以下文件，并將其放在類路徑中。 或者，只需復制下面給出的文件。 **`hornetq-configuration.xml`** ```java <configuration xmlns="urn:hornetq" xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance" xsi:schemaLocation="urn:hornetq /schema/hornetq-configuration.xsd"> <connectors> <connector name="netty"> <factory-class>org.hornetq.integration.transports.netty.NettyConnectorFactory</factory-class> <param key="host" value="${hornetq.remoting.netty.host:localhost}"/> <param key="port" value="${hornetq.remoting.netty.port:5445}"/> </connector> </connectors> <acceptors> <acceptor name="netty"> <factory-class>org.hornetq.integration.transports.netty.NettyAcceptorFactory</factory-class> <param key="host" value="${hornetq.remoting.netty.host:localhost}"/> <param key="port" value="${hornetq.remoting.netty.port:5445}"/> </acceptor> </acceptors> <security-settings> <security-setting match="#"> <permission type="createTempQueue" roles="guest"/> <permission type="deleteTempQueue" roles="guest"/> <permission type="consume" roles="guest"/> <permission type="send" roles="guest"/> </security-setting> </security-settings> <address-settings> <!--default for catch all--> <address-setting match="#"> <dead-letter-address>jms.queue.DLQ</dead-letter-address> <expiry-address>jms.queue.ExpiryQueue</expiry-address> <redelivery-delay>0</redelivery-delay> <max-size-bytes>-1</max-size-bytes> <page-size-bytes>10485760</page-size-bytes> <message-counter-history-day-limit>10</message-counter-history-day-limit> </address-setting> </address-settings> <paging-directory>${hornetq.data.dir}/paging</paging-directory> <bindings-directory>${hornetq.data.dir}/bindings</bindings-directory> <journal-directory>${hornetq.data.dir}/journal</journal-directory> <large-messages-directory>${hornetq.data.dir}/large-messages</large-messages-directory> </configuration> ``` **`hornetq-jms.xml`** ```java <configuration xmlns="urn:hornetq" xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance" xsi:schemaLocation="urn:hornetq /schema/hornetq-jms.xsd"> <connection-factory name="NettyConnectionFactory"> <connectors> <connector-ref connector-name="netty"/> </connectors> <entries> <entry name="/ConnectionFactory"/> <entry name="/XAConnectionFactory"/> </entries> </connection-factory> <queue name="ExampleQueue"> <entry name="/queue/ExampleQueue"/> </queue> <topic name="ExampleTopic"> <entry name="/topic/ExampleTopic"/> </topic> </configuration> ``` **`hornetq-users.xml`** ```java <configuration xmlns="urn:hornetq" xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance" xsi:schemaLocation="urn:hornetq /schema/hornetq-users.xsd"> <!-- the default user. this is used where username is null--> <defaultuser name="guest" password="guest"> <role name="guest"/> </defaultuser> </configuration> ``` 步驟 5）在類路徑中復制`jndi.properties`。 ```java java.naming.factory.initial=org.jnp.interfaces.NamingContextFactory java.naming.factory.url.pkgs=org.jboss.naming:org.jnp.interfaces ``` 步驟 6）配置記錄器，以更好地捕獲信息。 ```java # Create a STDOUT appender log4j.appender.STDOUT=org.apache.log4j.ConsoleAppender log4j.appender.STDOUT.layout=org.apache.log4j.PatternLayout log4j.appender.STDOUT.layout.ConversionPattern=%05p | %m%n # Default everything to WARN log4j.rootCategory=WARN, STDOUT # Enable this application log level to the lowest. log4j.category.com.howtodoinjava=TRACE log4j.category.org.jnp.server=INFO log4j.category.org.hornetq=INFO log4j.category.org.springframework=INFO ``` 步驟 7）到目前為止，已經配置了 hornetq 服務器和 jndi。 現在，將它們插入`spring.xml`和`spring.properties`中的 spring 框架。 **`spring.xml`** ```java <?xml version="1.0" encoding="UTF-8" standalone="no"?> <beans xmlns="http://www.springframework.org/schema/beans" xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance" xmlns:context="http://www.springframework.org/schema/context" xsi:schemaLocation="http://www.springframework.org/schema/beans http://www.springframework.org/schema/beans/spring-beans-2.5.xsd http://www.springframework.org/schema/context http://www.springframework.org/schema/context/spring-context-2.5.xsd"> <context:annotation-config /> <context:property-placeholder location="classpath:config/server/spring.properties" /> <bean name ="namingServerImpl" class="org.jnp.server.NamingBeanImpl" init-method="start" destroy-method="stop"> </bean> <!-- JNDI server. Disable this if you don't want JNDI --> <bean name="namingServer" class="org.jnp.server.Main" init-method="start" destroy-method="stop"> <property name="namingInfo" ref="namingServerImpl"></property> <property name="port" value="1099"></property> <property name="bindAddress" value="localhost"></property> <property name="rmiPort" value="1098"></property> <property name="rmiBindAddress" value="localhost"></property> </bean> <!-- MBean server --> <bean name="mbeanServer" class="java.lang.management.ManagementFactory" factory-method="getPlatformMBeanServer"> </bean> <!-- The core configuration --> <bean name="fileConfiguration" class="org.hornetq.core.config.impl.FileConfiguration" init-method="start" destroy-method="stop"> </bean> <!-- The security manager --> <bean name="hornetQSecurityManagerImpl" class="org.hornetq.spi.core.security.HornetQSecurityManagerImpl"> </bean> <!-- The core server --> <bean name="hornetQServerImpl" class="org.hornetq.core.server.impl.HornetQServerImpl"> <constructor-arg ref="fileConfiguration" /> <constructor-arg ref="mbeanServer" /> <constructor-arg ref="hornetQSecurityManagerImpl" /> </bean> <!-- The JMS server --> <bean name="jmsServerManagerImpl" class="org.hornetq.jms.server.impl.JMSServerManagerImpl" init-method="start" destroy-method="stop"> <constructor-arg ref="hornetQServerImpl" /> </bean> <bean name="connectionFactory" class="org.hornetq.jms.client.HornetQConnectionFactory" > <constructor-arg> <bean class="org.hornetq.api.core.TransportConfiguration"> <constructor-arg value="org.hornetq.integration.transports.netty.NettyConnectorFactory" /> <constructor-arg> <map key-type="java.lang.String" value-type="java.lang.Object"> <entry key="port" value="5445"></entry> </map> </constructor-arg> </bean> </constructor-arg> </bean> <bean name="jmsTemplate" class="org.springframework.jms.core.JmsTemplate"> <property name="connectionFactory" ref="connectionFactory"></property> </bean> <bean name="messageProducerClient" class="com.howtodoinjava.hornetq.demo.MessageProducerClient"> <property name="jmsTemplate" ref="jmsTemplate"></property> </bean> <bean name="messageConsumerClient" class="com.howtodoinjava.hornetq.demo.MessageConsumerClient"> <property name="jmsTemplate" ref="jmsTemplate"></property> </bean> </beans> ``` **`spring.properties`** ```java hornetq.data.dir=${hornetq.spring.examples.home}/hornetq-data org.hornetq.logger-delegate-factory-class-name=org.hornetq.integration.logging.Log4jLogDelegateFactory ``` 步驟 8）首先加載 Spring 容器。 它還將驗證我們所有的配置文件。 **`SpringContainerLoader.java`** ```java package com.howtodoinjava.hornetq.demo; import org.springframework.context.support.FileSystemXmlApplicationContext; public class SpringContainerLoader { public static FileSystemXmlApplicationContext loadEnvironment() { final FileSystemXmlApplicationContext context = new FileSystemXmlApplicationContext("classpath:config/server/spring.xml"); context.registerShutdownHook(); context.start(); return context; } } ``` 步驟 8）現在，我將編寫消息生產者和消息使用者客戶端。 **`MessageProducerClient.java`** ```java package com.howtodoinjava.hornetq.demo; import javax.jms.JMSException; import javax.jms.MessageProducer; import javax.jms.Session; import javax.jms.TextMessage; import org.apache.commons.logging.Log; import org.apache.commons.logging.LogFactory; import org.springframework.jms.core.JmsTemplate; import org.springframework.jms.core.ProducerCallback; public class MessageProducerClient implements Runnable { private static Log log = LogFactory.getLog(MessageProducerClient.class); private static int counter = 1; private JmsTemplate jmsTemplate; public void setJmsTemplate(JmsTemplate jmsTemplate) { this.jmsTemplate = jmsTemplate; } @Override public void run() { jmsTemplate.execute("ExampleQueue", new ProducerCallback<Object>() { @Override public Object doInJms(Session session, MessageProducer producer) throws JMSException { while (true) { TextMessage msg = session.createTextMessage("Message number : " + counter++); log.trace("Sending msg: " + msg); producer.send(msg); try { Thread.sleep(2000); } catch (InterruptedException e) { e.printStackTrace(); } } } }); } } ``` **`MessageConsumerClient.java`** ```java package com.howtodoinjava.hornetq.demo; import javax.jms.JMSException; import javax.jms.Message; import javax.jms.MessageConsumer; import javax.jms.Queue; import javax.jms.Session; import org.apache.commons.logging.Log; import org.apache.commons.logging.LogFactory; import org.springframework.jms.core.JmsTemplate; import org.springframework.jms.core.SessionCallback; public class MessageConsumerClient implements Runnable { private static Log log = LogFactory.getLog(MessageConsumerClient.class); private JmsTemplate jmsTemplate; public void setJmsTemplate(JmsTemplate jmsTemplate) { this.jmsTemplate = jmsTemplate; } @Override public void run() { log.info("Message Consumer is just started !!"); boolean startConn = true; jmsTemplate.execute(new SessionCallback<Object>() { @Override public Object doInJms(Session session) throws JMSException { Queue queue = session.createQueue("ExampleQueue"); MessageConsumer consumer = session.createConsumer(queue); while (true) { Message msg = consumer.receive(); log.trace("Received msg: " + msg); } } }, startConn); } } ``` 步驟 9）現在該測試整個代碼和消息傳遞功能了。 **`HornetQMessagingTest.java`** ```java package com.howtodoinjava.hornetq.demo; import org.springframework.context.ApplicationContext; public class HornetQMessagingTest { public static void main(String[] args) throws InterruptedException { //Load configurations ApplicationContext context = SpringContainerLoader.loadEnvironment(); //Start the message producer new Thread((Runnable)context.getBean("messageProducerClient")).start(); //Start the message consumer new Thread((Runnable)context.getBean("messageConsumerClient")).start(); } } ``` 在測試類之上運行會在下面生成日志，以驗證 Spring3 和 hornetq 集成成功。 ```java INFO | Refreshing org.springframework.context.support.FileSystemXmlApplicationContext@aa9835: startup date [Mon Mar 25 09:23:26 IST 2013]; root of context hierarchy INFO | Loading XML bean definitions from class path resource [config/server/spring.xml] INFO | Loading properties file from class path resource [config/server/spring.properties] INFO | Pre-instantiating singletons in org.springframework.beans.factory.support.DefaultListableBeanFactory@1b4fad5: defining beans [org.springframework.context.annotation.internalConfigurationAnnotationProcessor,org.springframework.context.annotation.internalAutowiredAnnotationProcessor,org.springframework.context.annotation.internalRequiredAnnotationProcessor,org.springframework.context.annotation.internalCommonAnnotationProcessor,org.springframework.beans.factory.config.PropertyPlaceholderConfigurer#0,namingServerImpl,namingServer,mbeanServer,fileConfiguration,hornetQSecurityManagerImpl,hornetQServerImpl,jmsServerManagerImpl,connectionFactory,jmsTemplate,messageProducerClient,messageConsumerClient]; root of factory hierarchy 25 Mar, 2013 9:23:28 AM org.hornetq.core.logging.impl.JULLogDelegate info INFO: live server is starting.. 25 Mar, 2013 9:23:28 AM org.hornetq.core.logging.impl.JULLogDelegate warn WARNING: AIO wasn't located on this platform, it will fall back to using pure Java NIO. If your platform is Linux, install LibAIO to enable the AIO journal 25 Mar, 2013 9:23:28 AM org.hornetq.core.logging.impl.JULLogDelegate info INFO: Using NIO Journal 25 Mar, 2013 9:23:28 AM org.hornetq.core.logging.impl.JULLogDelegate warn WARNING: Security risk! It has been detected that the cluster admin user and password have not been changed from the installation default. Please see the HornetQ user guide, cluster chapter, for instructions on how to do this. 25 Mar, 2013 9:23:30 AM org.hornetq.core.logging.impl.JULLogDelegate info INFO: Started Netty Acceptor version 3.1.5.GA-r1772 25 Mar, 2013 9:23:30 AM org.hornetq.core.logging.impl.JULLogDelegate info INFO: HornetQ Server version 2.0.0.GA (Hornet Queen, 113) started INFO | Message Consumer is just started !! TRACE | Sending msg: HornetQMessage[null]:PERSISTENT TRACE | Received msg: HornetQMessage[ID:8e74da0e-94ff-11e2-bbba-002564ac1704:0000000000000000]:PERSISTENT TRACE | Sending msg: HornetQMessage[null]:PERSISTENT TRACE | Received msg: HornetQMessage[ID:8e74da0e-94ff-11e2-bbba-002564ac1704:1000000000000000]:PERSISTENT TRACE | Sending msg: HornetQMessage[null]:PERSISTENT TRACE | Received msg: HornetQMessage[ID:8e74da0e-94ff-11e2-bbba-002564ac1704:2000000000000000]:PERSISTENT TRACE | Sending msg: HornetQMessage[null]:PERSISTENT TRACE | Received msg: HornetQMessage[ID:8e74da0e-94ff-11e2-bbba-002564ac1704:3000000000000000]:PERSISTENT ``` 如有任何問題，請先確認以下幾點： * 所有配置文件都在類路徑中。 * lib 文件夾中存在的兩個 jar 文件包含在類路徑中。 作為參考，我給出了目錄結構的快照。  [**源代碼下載**](https://docs.google.com/file/d/0B7yo2HclmjI4ME5IN3ZhNHU1Q1E/edit?usp=sharing "Spring3 hornetq integration source code download") **祝您學習愉快！**
